Suzuki DF 25A Parts Listings - 2016
S/N 02504F-610001 to 02504F-61XXXX
Fig. 340 - PTT Motor
| Ref# | Part Number | Description | Req Qty* | Price Each | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 38100-94L02 PTT Motor Assembly
SKU: 38100-94L02 Weight: 5.000000 Brand: Price: $ 651.68 |
PTT Motor Assembly | 1 | $ 651.68 | ||
| 2 | 31111-89J00 Screw (NLA)
SKU: 31111-89J00 Weight: 0.100000 Brand: Price: $ 4.50 |
Screw (NLA) | 2 | $ 4.50 | ||
| 3 | 31311-89J00 Armature (NLA)
SKU: 31311-89J00 Weight: 5.000000 Brand: Price: $ 334.64 |
Armature (NLA) | 1 | $ 334.64 | ||
| 4 | 31123-89J00 O-Ring
SKU: 31123-89J00 Weight: 0.060000 Brand: Price: $ 12.29 |
O-Ring | 1 | $ 12.29 | ||
| 5 | 31173-94L00 Brush Holder
SKU: 31173-94L00 Weight: 1.000000 Brand: Price: $ 396.51 |
Brush Holder | 1 | $ 396.51 |
Req Qty* is the total number of parts on the assembly. It is not the package quantity.
All Pricing is for each.
The information on this page is specific to the model and year and/or serial number shown in the header above.
Please verify your model and serial number before placing your order.
