Suzuki DF 250AP Parts Listings - 2015
S/N 25003P-510001 to 25003P-51XXXX
Fig. 523 - Opt: Harness (2)
| Ref# | Part Number | Description | Req Qty* | Price Each | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 33925-93J00 ECU/BCM Cushion
SKU: 33925-93J00 Weight: 0.250000 Brand: Price: $ 8.27 |
ECU/BCM Cushion | 2 | $ 8.27 | ||
| 2 | 33926-98J00 Terminal Resistor
SKU: 33926-98J00 Weight: 0.060000 Brand: Price: $ 5.98 |
Terminal Resistor | 4 | $ 5.98 | ||
| 3 | 36621-98J00 Dual Engine/Single Station Harness
SKU: 36621-98J00 Weight: 0.620000 Brand: Price: $ 114.66 |
Dual Engine/Single Station Harness | 2 | $ 114.66 | ||
| 4 | 36615-96300 Resin Terminal
SKU: 36615-96300 Weight: 0.060000 Brand: Price: $ 1.31 |
Resin Terminal | 8 | $ 1.31 | ||
| 5 | 36625-98J10 Battery Wire Assembly
SKU: 36625-98J10 Weight: 0.500000 Brand: Price: $ 94.03 |
Battery Wire Assembly | 2 | $ 94.03 | ||
| 6 | 09481-30501 30 Amp Fuse
SKU: 09481-30501 Weight: 0.060000 Brand: Price: $ 2.33 |
30 Amp Fuse | 2 | $ 2.33 | ||
| 7 | 36770-98J20 Boat Control Module - Quad
SKU: 36770-98J20 Weight: 1.000000 Brand: Price: $ 557.36 |
Boat Control Module - Quad | 2 | $ 557.36 | ||
| 8 | 36775-98J00 BCM Holder (L)
SKU: 36775-98J00 Weight: 0.100000 Brand: Price: $ 1.37 |
BCM Holder (L) | 2 | $ 1.37 | ||
| 9 | 36776-98J00 BCM Holder (R)
SKU: 36776-98J00 Weight: 0.100000 Brand: Price: $ 1.37 |
BCM Holder (R) | 2 | $ 1.37 | ||
| 10 | 37100-98J21 Dual Engine Control Panel
SKU: 37100-98J21 Weight: 0.480000 Brand: Price: $ 536.17 |
Dual Engine Control Panel | 2 | $ 536.17 | ||
| 11 | 37112-98J10 Nut (NLA)
SKU: 37112-98J10 Weight: 0.100000 Brand: Price: $ 16.54 |
Nut (NLA) | 2 | $ 16.54 | ||
| 12 | 38500-93J90 Warning Buzzer
SKU: 38500-93J90 Weight: 0.060000 Brand: Price: $ 39.28 |
Warning Buzzer | 2 | $ 39.28 | ||
| 13 | 33925-93J00 ECU/BCM Cushion
SKU: 33925-93J00 Weight: 0.250000 Brand: Price: $ 8.27 |
ECU/BCM Cushion | 2 | $ 8.27 | ||
| 14 | 36622-98J00 Dual Station Main Harness
SKU: 36622-98J00 Weight: 3.000000 Brand: Price: $ 122.81 |
Dual Station Main Harness | 2 | $ 122.81 | ||
| 15 | 09481-10501 10 Amp Fuse
SKU: 09481-10501 Weight: 0.062500 Brand: Price: $ 2.06 |
10 Amp Fuse | 2 | $ 2.06 | ||
| 16 | 36623-98J40 BCM Harness No 1
SKU: 36623-98J40 Weight: 1.000000 Brand: Price: $ 913.69 |
BCM Harness No 1 | 1 | $ 913.69 | ||
| 17 | 36770-98J20 Boat Control Module - Quad
SKU: 36770-98J20 Weight: 1.000000 Brand: Price: $ 557.36 |
Boat Control Module - Quad | 2 | $ 557.36 | ||
| 18 | 36775-98J00 BCM Holder (L)
SKU: 36775-98J00 Weight: 0.100000 Brand: Price: $ 1.37 |
BCM Holder (L) | 2 | $ 1.37 | ||
| 19 | 36776-98J00 BCM Holder (R)
SKU: 36776-98J00 Weight: 0.100000 Brand: Price: $ 1.37 |
BCM Holder (R) | 2 | $ 1.37 | ||
| 20 | 37100-98J21 Dual Engine Control Panel
SKU: 37100-98J21 Weight: 0.480000 Brand: Price: $ 536.17 |
Dual Engine Control Panel | 2 | $ 536.17 | ||
| 21 | 37112-98J10 Nut (NLA)
SKU: 37112-98J10 Weight: 0.100000 Brand: Price: $ 16.54 |
Nut (NLA) | 2 | $ 16.54 | ||
| 22 | 38500-93J90 Warning Buzzer
SKU: 38500-93J90 Weight: 0.060000 Brand: Price: $ 39.28 |
Warning Buzzer | 2 | $ 39.28 |
Req Qty* is the total number of parts on the assembly. It is not the package quantity.
All Pricing is for each.
The information on this page is specific to the model and year and/or serial number shown in the header above.
Please verify your model and serial number before placing your order.
