Suzuki DF 150 Parts Listings
S/N 15002F-410001 to 15002F-41XXXX
S/N 15002Z-410001 to 15002Z-41XXXX
Fig. 140 - Engine Holder
| Ref# | Part Number | Description | Req Qty* | Price Each | Order | Remarks |
|---|---|---|---|---|---|---|
| 1-1 | 51110-96J23-0EP HOLDER COMP,ENG
SKU: 51110-96J23-0EP Weight: 0.000000 Brand: Price: $ 1,146.89 |
HOLDER COMP,ENG | 1 | $ 1,146.89 | ||
| 1-2 | 51111-96J00-Y5S Engine Holder
SKU: 51111-96J00-Y5S Weight: 10.000000 Brand: Price: $ 1,089.50 |
Engine Holder | 1 | $ 1,089.50 | White | |
| 2 | 16519-93J00 Engine Holder Seal
SKU: 16519-93J00 Weight: 0.060000 Brand: Price: $ 5.02 |
Engine Holder Seal | 1 | $ 5.02 | ||
| 3 | 51211-96J00 Engine Holder Gasket
SKU: 51211-96J00 Weight: 8.000000 Brand: Price: $ 73.93 |
Engine Holder Gasket | 1 | $ 73.93 | ||
| 4 | 51115-90J10 Water Return Union
SKU: 51115-90J10 Weight: 0.250000 Brand: Price: $ 10.54 |
Water Return Union | 1 | $ 10.54 | ||
| 5 | 09180-06289 Spacer
SKU: 09180-06289 Weight: 0.100000 Brand: Price: $ 2.56 |
Spacer | 1 | $ 2.56 | ||
| 6 | 09280-26006 O-Ring
SKU: 09280-26006 Weight: 0.060000 Brand: Price: $ 2.80 |
O-Ring | 1 | $ 2.80 | ||
| 7 | 01550-06257 BOLT
SKU: 01550-06257 Weight: 0.060000 Brand: Price: $ 2.33 |
BOLT | 1 | $ 2.33 | ||
| 8 | 09206-08001 Knock Pin (8x11)
SKU: 09206-08001 Weight: 0.060000 Brand: Price: $ 1.78 |
Knock Pin (8x11) | 2 | $ 1.78 | ||
| 9 | 51120-96J02 Mount Oil Seal Cover Assembly
SKU: 51120-96J02 Weight: 1.000000 Brand: Price: $ 114.62 |
Mount Oil Seal Cover Assembly | 1 | $ 114.62 | ||
| 10 | 51120-96J02 Mount Oil Seal Cover Assembly
SKU: 51120-96J02 Weight: 1.000000 Brand: Price: $ 114.62 |
Mount Oil Seal Cover Assembly | 1 | $ 114.62 | ||
| 11 | 51124-93J01 Oil Seal
SKU: 51124-93J01 Weight: 0.060000 Brand: Price: $ 7.75 |
Oil Seal | 2 | $ 7.75 | ||
| 12 | 51125-93J00 Scrapper
SKU: 51125-93J00 Weight: 0.060000 Brand: Price: $ 11.18 |
Scrapper | 1 | $ 11.18 | ||
| 13 | 51123-96J02 Mount Oil Seal Cover Gasket
SKU: 51123-96J02 Weight: 0.060000 Brand: Price: $ 8.79 |
Mount Oil Seal Cover Gasket | 1 | $ 8.79 | ||
| 14 | 09103-08109 Bolt (8x120)
SKU: 09103-08109 Weight: 0.060000 Brand: Price: $ 3.22 |
Bolt (8x120) | 1 | $ 3.22 | ||
| 15 | 01550-0830A BOLT
SKU: 01550-0830A Weight: 0.060000 Brand: Price: $ 3.09 |
BOLT | 7 | $ 3.09 | ||
| 16 | 09206-08001 Knock Pin (8x11)
SKU: 09206-08001 Weight: 0.060000 Brand: Price: $ 1.78 |
Knock Pin (8x11) | 2 | $ 1.78 | ||
| 17 | 51140-96J00 Engine Holder Cover
SKU: 51140-96J00 Weight: 0.100000 Brand: Price: $ 60.65 |
Engine Holder Cover | 1 | $ 60.65 | ||
| 18 | 51142-96J00 Engine Holder Cover Gasket
SKU: 51142-96J00 Weight: 0.100000 Brand: Price: $ 4.21 |
Engine Holder Cover Gasket | 1 | $ 4.21 | ||
| 19 | 01550-06207 BOLT
SKU: 01550-06207 Weight: 0.060000 Brand: Price: $ 2.33 |
BOLT | 2 | $ 2.33 | ||
| 20 | 51161-96J01 Engine Holder Water Jacket Cover
SKU: 51161-96J01 Weight: 0.125000 Brand: Price: $ 55.94 |
Engine Holder Water Jacket Cover | 1 | $ 55.94 | ||
| 21 | 51162-96J00 Engine Holder Water Jacket Cover Gasket
SKU: 51162-96J00 Weight: 0.200000 Brand: Price: $ 8.21 |
Engine Holder Water Jacket Cover Gasket | 1 | $ 8.21 | ||
| 22 | 01550-06207 BOLT
SKU: 01550-06207 Weight: 0.060000 Brand: Price: $ 2.33 |
BOLT | 6 | $ 2.33 | ||
| 23 | 51170-96J01 Water Indicator Bracket
SKU: 51170-96J01 Weight: 0.060000 Brand: Price: $ 10.60 |
Water Indicator Bracket | 1 | $ 10.60 | ||
| 24 | 09116-06121 Bolt (6x25)
SKU: 09116-06121 Weight: 0.060000 Brand: Price: $ 2.72 |
Bolt (6x25) | 1 | $ 2.72 | ||
| 25 | 09160-18031 Exhaust Plug Gasket
SKU: 09160-18031 Weight: 0.060000 Brand: Price: $ 2.46 |
Exhaust Plug Gasket | 1 | $ 2.46 | ||
| 26 | 09248-18010 Exhaust Plug
SKU: 09248-18010 Weight: 0.080000 Brand: Price: $ 8.58 |
Exhaust Plug | 1 | $ 8.58 | ||
| 27 | 09116-10175 Bolt (10x50)
SKU: 09116-10175 Weight: 0.125000 Brand: Price: $ 6.90 |
Bolt (10x50) | 6 | $ 6.90 | ||
| 28 | 09116-10137 Bolt (10x70)
SKU: 09116-10137 Weight: 0.120000 Brand: Price: $ 8.02 |
Bolt (10x70) | 2 | $ 8.02 | ||
| 29 | 01550-08307 BOLT
SKU: 01550-08307 Weight: 0.060000 Brand: Price: $ 3.59 |
BOLT | 1 | $ 3.59 | ||
| 30 | 54121-96J01 Upper Thrust Mount
SKU: 54121-96J01 Weight: 0.100000 Brand: Price: $ 129.75 |
Upper Thrust Mount | 1 | $ 129.75 | ||
| 31 | 54130-96J02 MOUNT,UPR
SKU: 54130-96J02 Weight: 0.000000 Brand: Price: $ 62.19 |
MOUNT,UPR | 2 | $ 62.19 | ||
| 32 | 54112-96J02 Upper Mount Bolt (14x227)
SKU: 54112-96J02 Weight: 0.250000 Brand: Price: $ 54.37 |
Upper Mount Bolt (14x227) | 2 | $ 54.37 | ||
| 33 | 29159-93J00 Upper Mount Bolt Nut
SKU: 29159-93J00 Weight: 0.060000 Brand: Price: $ 13.25 |
Upper Mount Bolt Nut | 2 | $ 13.25 | ||
| 34 | 09160-15051 Upper Mount Bolt Washer
SKU: 09160-15051 Weight: 0.100000 Brand: Price: $ 1.96 |
Upper Mount Bolt Washer | 2 | $ 1.96 | ||
| 35 | 54137-93J02 Upper Mount Cover
SKU: 54137-93J02 Weight: 1.000000 Brand: Price: $ 82.13 |
Upper Mount Cover | 1 | $ 82.13 | ||
| 36 | 09116-10135 Bolt (10x95)
SKU: 09116-10135 Weight: 0.200000 Brand: Price: $ 8.85 |
Bolt (10x95) | 1 | $ 8.85 | ||
| 37 | 09116-10175 Bolt (10x50)
SKU: 09116-10175 Weight: 0.125000 Brand: Price: $ 6.90 |
Bolt (10x50) | 2 | $ 6.90 | ||
| 39 | 54122-96J01 SPACER,UPPER MO
SKU: 54122-96J01 Weight: 0.000000 Brand: Price: $ 6.22 |
SPACER,UPPER MO | 2 | $ 6.22 |
Req Qty* is the total number of parts on the assembly. It is not the package quantity.
All Pricing is for each.
The information on this page is specific to the model and year and/or serial number shown in the header above.
Please verify your model and serial number before placing your order.
