Suzuki DT 140 Parts Listings 1983 to 1985
Fig. 5 - Silencer - Motor Bracket
| Ref# | Part Number | Description | Req Qty* | Price Each | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 13855-95210 Silencer Gasket
SKU: 13855-95210 Weight: 0.060000 Brand: Price: $ 3.99 |
Silencer Gasket | 4 | $ 3.99 | ||
| 2 | 13811-94601 Silencer Case (NLA)
SKU: 13811-94601 Weight: 2.000000 Brand: Price: $ 45.93 |
Silencer Case (NLA) | 1 | $ 45.93 | ||
| 3 | 08322-01067 Washer (6.5x13x1.0)
SKU: 08322-01067 Weight: 0.060000 Brand: Price: $ 1.85 |
Washer (6.5x13x1.0) | 1 | $ 1.85 | ||
| 4 | 08321-01067 Lock Washer
SKU: 08321-01067 Weight: 0.060000 Brand: Price: $ 1.85 |
Lock Washer | 1 | $ 1.85 | ||
| 5 | 09100-06038 Bolt (6x50)
SKU: 09100-06038 Weight: 0.060000 Brand: Price: $ 1.54 |
Bolt (6x50) | 1 | $ 1.54 | ||
| 6-1 | 08321-01067 Lock Washer
SKU: 08321-01067 Weight: 0.060000 Brand: Price: $ 1.85 |
Lock Washer | 11 | $ 1.85 | 1983 to 1984 | |
| 6-2 | 08321-01067 Lock Washer
SKU: 08321-01067 Weight: 0.060000 Brand: Price: $ 1.85 |
Lock Washer | 8 | $ 1.85 | 1985 | |
| 7-1 | 01500-06167 BOLT
SKU: 01500-06167 Weight: 0.125000 Brand: Price: $ 1.97 |
BOLT | 11 | $ 1.97 | 1983 to 1984 | |
| 7-2 | 01500-06167 BOLT
SKU: 01500-06167 Weight: 0.125000 Brand: Price: $ 1.97 |
BOLT | 8 | $ 1.97 | 1985 | |
| 8 | 13853-94510 Silencer Gasket (NLA)
SKU: 13853-94510 Weight: 0.140000 Brand: Price: $ 20.94 |
Silencer Gasket (NLA) | 1 | $ 20.94 | ||
| 9-1 | 13812-94513 Silencer Cover (NLA)
SKU: 13812-94513 Weight: 0.100000 Brand: Price: $ 13.50 |
Silencer Cover (NLA) | 1 | $ 13.50 | 1983 to 1984 | |
| 9-2 | 13812-94514 Silencer Cover (NLA)
SKU: 13812-94514 Weight: 0.100000 Brand: Price: $ 21.58 |
Silencer Cover (NLA) | 1 | $ 21.58 | 1985 | |
| 10 | 02142-05207 SCREW
SKU: 02142-05207 Weight: 0.060000 Brand: Price: $ 1.43 |
SCREW | 4 | $ 1.43 | ||
| 11 | 02152-05352 02112-15357
SKU: 02152-05352 Weight: 0.100000 Brand: Price: $ 0.55 |
02112-15357 | 6 | $ 0.55 | ||
| 12-1 | 09250-10030 CAP(OD:15)
SKU: 09250-10030 Weight: 0.100000 Brand: Price: $ 1.66 |
CAP(OD:15) | 4 | $ 1.66 | 1983 to 1985 | |
| 12-2 | 09250-15010 Plug
SKU: 09250-15010 Weight: 0.060000 Brand: Price: $ 1.88 |
Plug | 4 | $ 1.88 | 1985 | |
| 13 | 01550-05453 Bolt (5x45) (NLA)
SKU: 01550-05453 Weight: 1.000000 Brand: Price: $ 1.42 |
Bolt (5x45) (NLA) | 4 | $ 1.42 | ||
| 14 | 61458-95203 Safety Warning Mark (NLA)
SKU: 61458-95203 Weight: 0.100000 Brand: Price: $ 0.00 |
Safety Warning Mark (NLA) | 1 | $ 0.00 | 1983 | |
| 15 | 09401-06101 Clamp
SKU: 09401-06101 Weight: 0.060000 Brand: Price: $ 2.04 |
Clamp | 4 | $ 2.04 | ||
| 16 | 09355-30001-600 Hose (3x7x600)
SKU: 09355-30001-600 Weight: 0.200000 Brand: Price: $ 8.71 |
Hose (3x7x600) | 2 | $ 8.71 | 1983 | |
| 17 | 09355-30001-600 Hose (3x7x600)
SKU: 09355-30001-600 Weight: 0.200000 Brand: Price: $ 8.71 |
Hose (3x7x600) | 1 | $ 8.71 | L:600->400 1984 to 1985 | |
| 18 | 09355-30001-600 Hose (3x7x600)
SKU: 09355-30001-600 Weight: 0.200000 Brand: Price: $ 8.71 |
Hose (3x7x600) | 1 | $ 8.71 | L:600->120 1984 to 1985 | |
| 19 | 09404-08420 Clamp
SKU: 09404-08420 Weight: 0.125000 Brand: Price: $ 3.21 |
Clamp | 1 | $ 3.21 | ||
| 20 | 16710-95211 Check Valve
SKU: 16710-95211 Weight: 0.060000 Brand: Price: $ 17.43 |
Check Valve | 1 | $ 17.43 | ||
| 21 | 31911-94514-02M Starting Motor Bracket (NLA)
SKU: 31911-94514-02M Weight: 0.100000 Brand: Price: $ 35.54 |
Starting Motor Bracket (NLA) | 1 | $ 35.54 | ||
| 22 | 08322-01087 Washer
SKU: 08322-01087 Weight: 0.060000 Brand: Price: $ 1.85 |
Washer | 4 | $ 1.85 | ||
| 23 | 08321-01087 Lock Washer
SKU: 08321-01087 Weight: 0.060000 Brand: Price: $ 1.85 |
Lock Washer | 4 | $ 1.85 | ||
| 24 | 01500-08257 BOLT
SKU: 01500-08257 Weight: 0.060000 Brand: Price: $ 2.52 |
BOLT | 4 | $ 2.52 | ||
| 25 | 31912-94511 Starting Motor Band (NLA)
SKU: 31912-94511 Weight: 0.100000 Brand: Price: $ 4.40 |
Starting Motor Band (NLA) | 1 | $ 4.40 | 1983 to 1984 | |
| 26 | 31912-94600 Starting Motor Band (NLA)
SKU: 31912-94600 Weight: 0.100000 Brand: Price: $ 4.37 |
Starting Motor Band (NLA) | 1 | $ 4.37 | 1985 | |
| 27 | 08322-01087 Washer
SKU: 08322-01087 Weight: 0.060000 Brand: Price: $ 1.85 |
Washer | 2 | $ 1.85 | 1983 | |
| 28 | 08321-01087 Lock Washer
SKU: 08321-01087 Weight: 0.060000 Brand: Price: $ 1.85 |
Lock Washer | 2 | $ 1.85 | ||
| 29 | 01500-08257 BOLT
SKU: 01500-08257 Weight: 0.060000 Brand: Price: $ 2.52 |
BOLT | 2 | $ 2.52 |
Req Qty* is the total number of parts on the assembly. It is not the package quantity.
All Pricing is for each.
The information on this page is specific to the model and year and/or serial number shown in the header above.
Please verify your model and serial number before placing your order.
