Suzuki DF 250 Parts Listings - 2013
S/N 25003F-310001 to 25003F-31XXXX
S/N 25003Z-310001 to 25003Z-31XXXX


Fig. 166 - Drive Shaft Housing

Ref# Part Number Description Req Qty* Price Each Order Remarks
1 52111-93J11-0EP Drive Shaft Housing 1 $ 1,148.30
2 09116-10176 Bolt (10x44) 8 $ 6.81
3 09202-08006 Knock Pin (8x12) 2 $ 2.77
4 57130-87D10 Drive Shaft Bushing 1 $ 38.20
5 09387-39002 RING,DRIVE SHAF 1 $ 6.45
6 09125-06063 Screw (6x10) 1 $ 1.96
7 52131-93J00-0EP Extension Case (XX) 1 $ 979.03
Type: XX
8 09108-10115 Stud Bolt 6 $ 24.92
Type: XX
9 09108-12013 Extension Bolt 1 $ 31.89
Type: xx
10 09202-08006 Knock Pin (8x12) 2 $ 2.77
Type: XX
11 36894-87D00 Wire Lead (L:195) 1 $ 12.66
Mount Bracket to Housing
12 09125-06063 Screw (6x10) 1 $ 1.96
13 54151-93J00 Lower Thrust Mount (NLA) 1 $ 7.09

Not Available

14 54160-93J01 Lower Mount 2 $ 118.86
15 54112-93J00 Upper Mount Bolt 2 $ 73.85
16 09160-16050 Lower Mount Washer 2 $ 2.65
17 29159-93J00 Upper Mount Bolt Nut 2 $ 13.25
18 09160-16050 Lower Mount Washer 2 $ 2.65
19 54211-93J00-0EP Lower Mount Bracket 1 $ 181.09
20 54221-93J00 Lower Mount Cover (NLA) 2 $ 44.09
21 09116-10175 Bolt (10x50) 4 $ 6.90
22 54165-98J01 Lower Thrust Reverse Stopper 4 $ 7.77
23 09160-14066 Reverse Stopper Lower Washer 2 $ 9.08
24 29404-93J11 Clamp (L:65) 1 $ 1.57
25 29103-93J00 Bolt (6x12) 1 $ 2.05
26-1 55321-93J01 Protection Anode 1 $ 15.13
Type: X
26-2 55321-93J01 Protection Anode 2 $ 15.13
Type: XX
27-1 09116-06094 Bolt (6x15) 1 $ 2.28
Type: X
27-2 09116-06094 Bolt (6x15) 2 $ 2.28
Type: XX

Req Qty* is the total number of parts on the assembly. It is not the package quantity.
All Pricing is for each. The information on this page is specific to the model and year and/or serial number shown in the header above.

Please verify your model and serial number before placing your order.
