Suzuki DF 115A Parts Listings
S/N 11503F-310001 to 11503F-31XXXX
S/N 11503Z-310001 to 11503Z-31XXXX
Fig. 31 - Magneto
| Ref# | Part Number | Description | Req Qty* | Price Each | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 32102-92J20 Flywheel
SKU: 32102-92J20 Weight: 15.000000 Brand: Price: $ 1,138.02 |
Flywheel | 1 | $ 1,138.02 | ||
| 2 | 32120-92J00 Battery Charging Coil
SKU: 32120-92J00 Weight: 1.000000 Brand: Price: $ 598.71 |
Battery Charging Coil | 1 | $ 598.71 | ||
| 3 | 32160-92J00 CKP/Ignition Timing Coil
SKU: 32160-92J00 Weight: 0.250000 Brand: Price: $ 117.35 |
CKP/Ignition Timing Coil | 1 | $ 117.35 | ||
| 4 | 33220-50M10 Cam Position Sensor
SKU: 33220-50M10 Weight: 0.250000 Brand: Price: $ 115.36 |
Cam Position Sensor | 1 | $ 115.36 | ||
| 5 | 33833-91J00 Tube (6x8x250)
SKU: 33833-91J00 Weight: 0.125000 Brand: Price: $ 7.13 |
Tube (6x8x250) | 1 | $ 7.13 | L:250->100 | |
| 6 | 09103-06231 Bolt (6x35)
SKU: 09103-06231 Weight: 0.060000 Brand: Price: $ 2.81 |
Bolt (6x35) | 4 | $ 2.81 | ||
| 7 | 09103-16004 Bolt (16x50)
SKU: 09103-16004 Weight: 0.125000 Brand: Price: $ 10.05 |
Bolt (16x50) | 1 | $ 10.05 | ||
| 8 | 09160-16048 Washer (16.5x60x7.0)
SKU: 09160-16048 Weight: 0.350000 Brand: Price: $ 16.68 |
Washer (16.5x60x7.0) | 1 | $ 16.68 | ||
| 9 | 01547-06167 BOLT 6X16
SKU: 01547-06167 Weight: 0.060000 Brand: Price: $ 1.66 |
BOLT 6X16 | 1 | $ 1.66 | ||
| 10 | 09106-05030 Bolt (5x10)
SKU: 09106-05030 Weight: 0.060000 Brand: Price: $ 2.62 |
Bolt (5x10) | 2 | $ 2.62 | ||
| 11 | 08341-31059 Woodruff Key 5mm
SKU: 08341-31059 Weight: 0.060000 Brand: Price: $ 2.52 |
Woodruff Key 5mm | 1 | $ 2.52 |
Req Qty* is the total number of parts on the assembly. It is not the package quantity.
All Pricing is for each.
The information on this page is specific to the model and year and/or serial number shown in the header above.
Please verify your model and serial number before placing your order.
