Suzuki DF 140BG Parts Listings - 2022
S/N 14004F-240001 to 14004F-24XXXX
S/N DF 140BGZG 14004Z-240001 to 14004Z-24XXXX
Fig. 144 - Fuel Injector
| Ref# | Part Number | Description | Req Qty* | Price Each | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 15681-99L10 HOSE,FUEL(SEPAR
SKU: 15681-99L10 Weight: 0.000000 Brand: Price: $ 30.58 |
HOSE,FUEL(SEPAR | 1 | $ 30.58 | Separator to Delivery Pipe | |
| 2 | 15710-99L00 INJECTOR ASSY,F
SKU: 15710-99L00 Weight: 0.000000 Brand: Price: $ 45.69 |
INJECTOR ASSY,F | 4 | $ 45.69 | ||
| 3 | 15716-65DT0 Grommet Set
SKU: 15716-65DT0 Weight: 0.060000 Brand: Price: $ 19.06 |
Grommet Set | 4 | $ 19.06 | ||
| 4 | 15751-99L10 PIPE,DELIVERY
SKU: 15751-99L10 Weight: 0.000000 Brand: Price: $ 171.89 |
PIPE,DELIVERY | 1 | $ 171.89 | ||
| 5 | 09168-12013 Gasket
SKU: 09168-12013 Weight: 0.060000 Brand: Price: $ 3.46 |
Gasket | 2 | $ 3.46 | ||
| 6 | 09320-08062 Cushion
SKU: 09320-08062 Weight: 0.060000 Brand: Price: $ 13.65 |
Cushion | 4 | $ 13.65 | ||
| 7 | 09401-11425 Clip
SKU: 09401-11425 Weight: 0.060000 Brand: Price: $ 3.46 |
Clip | 2 | $ 3.46 | ||
| 8 | 01421-0820C 01421-0820C
SKU: 01421-0820C Weight: Brand: Price: $ 0.00 |
01421-0820C | 2 | $ 0.00 | ||
| 9 | 01550-12167 BOLT
SKU: 01550-12167 Weight: 0.100000 Brand: Price: $ 3.89 |
BOLT | 2 | $ 3.89 | ||
| 10 | 08316-1008C Nut
SKU: 08316-1008C Weight: 0.060000 Brand: Price: $ 0.00 |
Nut | 2 | $ 0.00 | ||
| 11 | 15830-99L00 JOINT COMP,FUEL
SKU: 15830-99L00 Weight: 0.000000 Brand: Price: $ 35.31 |
JOINT COMP,FUEL | 1 | $ 35.31 | ||
| 12 | 01550-0612C BOLT
SKU: 01550-0612C Weight: 0.060000 Brand: Price: $ 1.73 |
BOLT | 1 | $ 1.73 | ||
| 13 | 09280-08012 O-Ring
SKU: 09280-08012 Weight: 0.100000 Brand: Price: $ 3.73 |
O-Ring | 1 | $ 3.73 | ||
| 14 | 08316-1008C Nut
SKU: 08316-1008C Weight: 0.060000 Brand: Price: $ 0.00 |
Nut | 2 | $ 0.00 |
Req Qty* is the total number of parts on the assembly. It is not the package quantity.
All Pricing is for each.
The information on this page is specific to the model and year and/or serial number shown in the header above.
Please verify your model and serial number before placing your order.
