Suzuki DF 50 Parts Listings - 2010
S/N 05002F-010001 to 05002F-01XXXX
Fig. 2 - Cylinder Block
| Ref# | Part Number | Description | Req Qty* | Price Each | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 11291-87J00 Engine Hook (NLA)
SKU: 11291-87J00 Weight: 0.100000 Brand: Price: $ 7.68 |
Engine Hook (NLA) | 1 | $ 7.68 | ||
| 2 | 01550-08207 BOLT
SKU: 01550-08207 Weight: 0.060000 Brand: Price: $ 2.74 |
BOLT | 2 | $ 2.74 | ||
| 4 | 11301-87J40 BLOCK SET,CYLIN (NLA)
SKU: 11301-87J40 Weight: 0.000000 Brand: Price: $ 1,857.54 |
BLOCK SET,CYLIN (NLA) | 1 | $ 1,857.54 | Includes Ref# 3 5 to 13 | |
| 5 | 11117-89J20 Crankcase Bolt
SKU: 11117-89J20 Weight: 0.100000 Brand: Price: $ 6.35 |
Crankcase Bolt | 8 | $ 6.35 | ||
| 6 | 11261-87E10 Protection Anode Cover
SKU: 11261-87E10 Weight: 0.060000 Brand: Price: $ 16.83 |
Protection Anode Cover | 1 | $ 16.83 | ||
| 7 | 11265-87E10 Protection Cover Gasket
SKU: 11265-87E10 Weight: 0.060000 Brand: Price: $ 3.81 |
Protection Cover Gasket | 1 | $ 3.81 | ||
| 8 | 55321-87J01 Aluminum Anode
SKU: 55321-87J01 Weight: 0.125000 Brand: Price: $ 7.36 |
Aluminum Anode | 1 | $ 7.36 | ||
| 9 | 09206-13019 Knock Pin
SKU: 09206-13019 Weight: 0.062500 Brand: Price: $ 2.54 |
Knock Pin | 4 | $ 2.54 | ||
| 10 | 09246-08004 Plug (NLA)
SKU: 09246-08004 Weight: 0.100000 Brand: Price: $ 2.16 |
Plug (NLA) | 2 | $ 2.16 | ||
| 11 | 01550-06207 BOLT
SKU: 01550-06207 Weight: 0.060000 Brand: Price: $ 2.33 |
BOLT | 2 | $ 2.33 | ||
| 12 | 01550-08407 BOLT 8 X 40
SKU: 01550-08407 Weight: 0.060000 Brand: Price: $ 3.48 |
BOLT 8 X 40 | 8 | $ 3.48 | ||
| 13 | 09103-06281 Bolt (6x14)
SKU: 09103-06281 Weight: 0.060000 Brand: Price: $ 2.99 |
Bolt (6x14) | 1 | $ 2.99 |
Req Qty* is the total number of parts on the assembly. It is not the package quantity.
All Pricing is for each.
The information on this page is specific to the model and year and/or serial number shown in the header above.
Please verify your model and serial number before placing your order.
