Suzuki DF 40 Parts Listings - 1999
S/N 04001F-971001 to 04001F-97XXXX
Fig. 3 - Oil Seal Housing
| Ref# | Part Number | Description | Req Qty* | Price Each | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 11411-87J00-019 Upper Oil Seal Housing(NLA)
SKU: 11411-87J00-019 Weight: 0.500000 Brand: Price: $ 105.88 |
Upper Oil Seal Housing(NLA) | 1 | $ 105.88 | ||
| 2 | 11413-87J00 Upper Oil Seal Housing Gasket
SKU: 11413-87J00 Weight: 0.200000 Brand: Price: $ 6.55 |
Upper Oil Seal Housing Gasket | 1 | $ 6.55 | ||
| 3 | 11431-87J00 Under Oil Seal Housing
SKU: 11431-87J00 Weight: 0.250000 Brand: Price: $ 33.34 |
Under Oil Seal Housing | 1 | $ 33.34 | ||
| 4 | 11433-87J00 Under Oil Seal Housing Gasket
SKU: 11433-87J00 Weight: 0.060000 Brand: Price: $ 3.99 |
Under Oil Seal Housing Gasket | 1 | $ 3.99 | ||
| 5 | 11511-87J00 Ring Gear Cover (NLA)
SKU: 11511-87J00 Weight: 0.100000 Brand: Price: $ 82.25 |
Ring Gear Cover (NLA) | 1 | $ 82.25 | ||
| 6 | 11513-87J00 Flywheel Magneto Upper Cover (NLA)
SKU: 11513-87J00 Weight: 0.100000 Brand: Price: $ 31.07 |
Flywheel Magneto Upper Cover (NLA) | 1 | $ 31.07 | ||
| 7 | 09117-06031 Bolt (6x20)
SKU: 09117-06031 Weight: 0.060000 Brand: Price: $ 3.53 |
Bolt (6x20) | 2 | $ 3.53 | ||
| 8 | 09282-17009 Oil Seal (17x28x6)
SKU: 09282-17009 Weight: 0.060000 Brand: Price: $ 10.20 |
Oil Seal (17x28x6) | 1 | $ 10.20 | ||
| 9 | 01550-06207 BOLT
SKU: 01550-06207 Weight: 0.060000 Brand: Price: $ 2.33 |
BOLT | 8 | $ 2.33 | ||
| 10 | 01550-06507 BOLT
SKU: 01550-06507 Weight: 0.060000 Brand: Price: $ 2.95 |
BOLT | 1 | $ 2.95 | ||
| 11 | 03541-0516A SCREW
SKU: 03541-0516A Weight: 0.100000 Brand: Price: $ 1.38 |
SCREW | 7 | $ 1.38 | ||
| 12 | 04221-04089 PIN 4X8
SKU: 04221-04089 Weight: 0.060000 Brand: Price: $ 1.11 |
PIN 4X8 | 4 | $ 1.11 | ||
| 13 | 11531-87J00 Magneto Cover Seal (NLA)
SKU: 11531-87J00 Weight: 0.100000 Brand: Price: $ 7.78 |
Magneto Cover Seal (NLA) | 1 | $ 7.78 | ||
| 14 | 09169-06062 Washer (6.3x17x1.6)
SKU: 09169-06062 Weight: 0.060000 Brand: Price: $ 2.52 |
Washer (6.3x17x1.6) | 1 | $ 2.52 | ||
| 15 | 69711-93E11 Label (S.I.G.P)
SKU: 69711-93E11 Weight: 0.060000 Brand: Price: $ 4.45 |
Label (S.I.G.P) | 1 | $ 4.45 | ||
| 16 | 09320-08013 Grommet
SKU: 09320-08013 Weight: 0.060000 Brand: Price: $ 2.07 |
Grommet | 1 | $ 2.07 | ||
| 17 | 09320-20008 Cushion
SKU: 09320-20008 Weight: 0.100000 Brand: Price: $ 3.74 |
Cushion | 1 | $ 3.74 | ||
| 18 | 61472-93E33 LABEL,RECOIL,ST
SKU: 61472-93E33 Weight: 0.000000 Brand: Price: $ 7.74 |
LABEL,RECOIL,ST | 1 | $ 7.74 | ||
| 19 | 11174-99800 Breather Hose Set
SKU: 11174-99800 Weight: 0.500000 Brand: Price: $ 24.22 |
Breather Hose Set | 1 | $ 24.22 | ||
| 20 | 69712-93E10 Label S.I.G.P
SKU: 69712-93E10 Weight: 0.100000 Brand: Price: $ 4.03 |
Label S.I.G.P | 1 | $ 4.03 |
Req Qty* is the total number of parts on the assembly. It is not the package quantity.
All Pricing is for each.
The information on this page is specific to the model and year and/or serial number shown in the header above.
Please verify your model and serial number before placing your order.
