Suzuki DF 9.9 Parts Listings - 2006
S/N 00992F-680001 to 00992F-68XXXX
Fig. 49 - Engine Cover
| Ref# | Part Number | Description | Req Qty* | Price Each | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 61400-94J00-0EP Engine Cover Assembly
SKU: 61400-94J00-0EP Weight: 10.000000 Brand: Price: $ 469.27 |
Engine Cover Assembly | 1 | $ 469.27 | ||
| 2 | 61431-94J00-0EP Tilt Up Handle
SKU: 61431-94J00-0EP Weight: 0.100000 Brand: Price: $ 68.64 |
Tilt Up Handle | 1 | $ 68.64 | ||
| 3 | 03542-06169 SCREW
SKU: 03542-06169 Weight: 0.060000 Brand: Price: $ 2.16 |
SCREW | 3 | $ 2.16 | ||
| 4 | 61622-93E03 Recoil Starter Seal
SKU: 61622-93E03 Weight: 0.080000 Brand: Price: $ 12.23 |
Recoil Starter Seal | 1 | $ 12.23 | ||
| 5 | 61443-94J00 Starboard Engine Cover Stripe
SKU: 61443-94J00 Weight: 0.200000 Brand: Price: $ 41.27 |
Starboard Engine Cover Stripe | 1 | $ 41.27 | ||
| 6 | 61453-94J00 Port Engine Cover Stripe
SKU: 61453-94J00 Weight: 0.250000 Brand: Price: $ 41.27 |
Port Engine Cover Stripe | 1 | $ 41.27 | ||
| 7 | 68271-91J00-Y2D Suzuki Emblem
SKU: 68271-91J00-Y2D Weight: 0.060000 Brand: Price: $ 6.38 |
Suzuki Emblem | 1 | $ 6.38 | Front | |
| 8 | 61435-93E30 Rear Emblem Mark (9.9)
SKU: 61435-93E30 Weight: 0.060000 Brand: Price: $ 13.36 |
Rear Emblem Mark (9.9) | 1 | $ 13.36 | ||
| 10 | 61458-99E31 Engine Cover Label
SKU: 61458-99E31 Weight: 0.060000 Brand: Price: $ 11.87 |
Engine Cover Label | 1 | $ 11.87 | ||
| 11 | 69716-99E14 Fuel Limitation Label
SKU: 69716-99E14 Weight: 0.200000 Brand: Price: $ 3.98 |
Fuel Limitation Label | 1 | $ 3.98 | ||
| 12 | 61412-93E00 Engine Cover Hook
SKU: 61412-93E00 Weight: 0.060000 Brand: Price: $ 7.28 |
Engine Cover Hook | 1 | $ 7.28 | ||
| 13 | 61610-90L00 Fastener
SKU: 61610-90L00 Weight: 0.080000 Brand: Price: $ 40.56 |
Fastener | 1 | $ 40.56 | ||
| 14 | 61616-93EL0 Lever Pin
SKU: 61616-93EL0 Weight: 0.060000 Brand: Price: $ 7.55 |
Lever Pin | 1 | $ 7.55 | ||
| 15 | 09161-04012 Washer (4.2x11x1)
SKU: 09161-04012 Weight: 0.060000 Brand: Price: $ 1.51 |
Washer (4.2x11x1) | 1 | $ 1.51 | ||
| 16 | 09385-04003 Snap Pin
SKU: 09385-04003 Weight: 0.060000 Brand: Price: $ 2.41 |
Snap Pin | 1 | $ 2.41 | ||
| 17 | 61643-94J00 Screw
SKU: 61643-94J00 Weight: 0.100000 Brand: Price: $ 3.13 |
Screw | 2 | $ 3.13 | ||
| 18 | 59800-99J01 Tool Set
SKU: 59800-99J01 Weight: 0.100000 Brand: Price: $ 54.54 |
Tool Set | 1 | $ 54.54 | ||
| 19 | 68110-96110 Weather Cover (NLA)
SKU: 68110-96110 Weight: 0.100000 Brand: Price: $ 17.30 |
Weather Cover (NLA) | 1 | $ 17.30 |
Req Qty* is the total number of parts on the assembly. It is not the package quantity.
All Pricing is for each.
The information on this page is specific to the model and year and/or serial number shown in the header above.
Please verify your model and serial number before placing your order.
